OPT-MH40-110C

Delivery time 3-5 Workdays

  • 06.23.0056
High resolution, max compatible with 2MP industrial camera with 2/3" sensor Obtain images of... more
Product information "OPT-MH40-110C"
  • High resolution, max compatible with 2MP industrial camera with 2/3" sensor
  • Obtain images of uniform brightness with the built-in coaxial illumination
  • Object-space telecentric design

For more information on matching sensor formats and fields of view, please refer to the datasheet.

Lens mount: C
Sensor Size: 2/3"
Megapixel: 2
Image circle: 11 mm
Magnification: 4 ×
Working Distance: 110±3 mm
Aperture: 22.1
Distortion: 0.058 %
DOF: 0.11 mm
